Magnetic Sheet Rubber Magnet Fridge Magnet Paper Magnetic Roll For Industry
Rubber magnets are molded by mixing rubber with ferrite powder.
The absorption power is substantially weaker than anisotropic ferrite magnets, but machining can be performed easily after purchasing these products, as they can be cut with a pair of scissors or cutters.
The rubber magnets are in wide use all around us, for stationery, DIY arts and crafts as well as manufacturing industry products by taking advantage of their characteristics.
Advantages of Rubber Magnets
• Low cost.
• Can generally be rolled up for storage and ease of transporting around.
• Can print onto the vinyl surface to create bespoke visual displays.
• Can be produced in a customised manner for practicality e.g. adding ferrous sheet and printed vinyl so magnets would attract to the ferrous layer in magnetic maps.
• Can add adhesive backing layer.
Typical Applications of Flexible Magnets
• Vehicle magnetic graphics.
• Magnetic signs and displays (Point of Sale).
• Advertising.
• Magnetic maps, charts, music boards.
• Painting booth magnetic covers.
• Magnetic gaskets.
| Magnetic properties of flexible magnetic sheeting |
| Code | Br | Hcb | Hcj | (BH)max | Forming way | Size | | |
| T | KA/m | KA/m | KJ/m3 | Max Length(m) | Max Width(mm) | Height(mm) |
| YYR-01 | 0.13~0.18 | 80~120 | 100~160 | 4~6.4 | Calendering | 100 | 400 | 0.4~1.1 |
| YYR-02 | 0.18~0.22 | 100~140 | 120~190 | 6.4~8.0 | Calendering | 2 | 930 | 0.6~3 |
| YYR-03 | 0.21~0.239 | 140~165 | 150~210 | 8.0~10.4 | Calendering | 100 | 400 | 0.4~1.5 |
| YYR-04 | 0.24~0.265 | 15z`6~181 | 200~270 | 10.4~12.5 | Calendering | 2 | 400 | 0.6~6 |
Packing
Standard export package for air and sea shipping.
usually inner carton -→outer box (single layer and double layer) -→pallet and can be packaged per your requests.
+By Air: all the magnetic should be degaussed and we will use Iron sheet to shield.
+By Sea: we will place a pallet on the bottom of cartons.
Shipping
Express (TNT, DHL, FedEx, UPS, etc), Air, Ocean.
a: The weight is under 40Kgs, we recommend to send them in shielding boxes to you by Express.
b: The weight is between 40Kgs-100Kgs, it can be sent by Express or Air.
c: The weight is over 100Kgs, we recommend to send them by Ocean.
If you need it, please kindly advise me the following details:
a. Dimensions or drawing with tolerances.
b. Material grade or magnetic properties.
c. Isotropic or Anisotropic.
d. Whether need with PVC or adhesive.
e. Quantity and delivery terms.
Then I will provide the most competitive price for you.
Thanks for your cooperation!
